Controlled heating creates accurate, uniform and reliable pipe sockets.
Reliable and Standardized Pipe Joints with Belling Machines
Pipe belling machines are specialized end-of-line systems used to heat and form plastic pipe ends into precise socket profiles. This process enables pipes to be joined more easily while creating strong, uniform and leak-resistant connections. Pipe socketing technology is widely used in PVC pipe production lines, PP pipe extrusion lines, drainage systems and pressurized plastic pipe applications.
Sarem Makina develops automatic pipe belling and socketing machines with high production capacity, user-friendly controls and durable mechanical construction. Infrared heating technology provides homogeneous temperature distribution across the pipe surface, while controlled pressing and cooling preserve the required socket geometry. PLC and touchscreen controls allow operators to manage heating temperature, cycle time, pressing and cooling parameters accurately.
| Boru Çapı | Çevrim Süresi (sn) |
Boru Et Kalınlığı (mm) |
Sarbel 1 Adet / Saat |
Sarbel 2 Adet / Saat |
Sarbel 3 Adet / Saat |
|---|---|---|---|---|---|
| Ø32 | 15 | 1,8 | 230 | 460 | 830 |
| Ø40 | 15 | 1,8 | 230 | 460 | 830 |
| Ø50 | 15 | 1,8 | 230 | 460 | 830 |
| Ø58 | 18 | 4 | 200 | 400 | 450 |
| Ø75 | |||||
| S20 | 18 | 1,9 | 200 | 400 | 480 |
| S16 | 22 | 2,3 | — | — | 480 |
| S14 | 24 | 2,6 | — | — | 450 |
| Ø110 | |||||
| S20 | 24 | 2,7 | 150 | 150 | 340 |
| S16 | 26 | 3,4 | 140 | 140 | 313 |
| Silenta | 36 | 5,3 | 100 | 100 | 276 |
| Ø125 | |||||
| S20 | 29 | 3,1 | 102 | 124 | 156 |
| S16 | 32 | 3,9 | 100 | 112 | 144 |
| S14 | 36 | 4,3 | 90 | 100 | 120 |
| Ø160 | |||||
| S20 | 75 | 3,9 | 48 | 48 | 72 |
| S16 | 80 | 4,9 | 45 | 45 | 64 |
| S14 | 85 | 5,5 | 42 | 42 | 55 |
Tablonun devamını görmek için yatay kaydırın.
- Precision Socket Forming
- Infrared Heating System
- Automatic Pressing Cycle
- Controlled Pipe Cooling
- PLC Touchscreen Control
- Multiple Diameter Compatibility
Sarem Pipe Belling Technology
Sarem pipe belling machines heat and shape plastic pipe ends under controlled conditions, helping manufacturers achieve consistent socket dimensions and reliable joint quality. Automated heating, pressing and cooling processes maintain product standards while reducing operator intervention.
The advanced automation system allows each PVC pipe socketing machine to adapt to different pipe diameters and production speeds. It is suitable for drainage pipes, sewer pipes, pressure pipes and other plastic pipe applications requiring strong, dimensionally accurate and efficient socket formation.
Sarem Automatic Pipe Belling Machines
Sarem automatic pipe belling machines combine powerful heating, balanced pressing and controlled cooling technologies to improve quality consistency in plastic pipe production. Adjustable configurations enable manufacturers to process different pipe diameters and socket profiles on a single production platform.
Durable construction, long-life components and precise control systems make Sarem pipe socketing solutions a reliable investment for high-capacity manufacturing facilities. The engineering-focused design supports production stability, lower energy consumption, efficient operation and dependable after-sales technical support.
| Boru Çapı / Tip | Çevrim Süresi (sn) |
Boru Et Kalınlığı (mm) |
Sarbel 1 Adet / Saat |
Sarbel 2 Adet / Saat |
Sarbel 3 Adet / Saat |
|---|---|---|---|---|---|
| Ø32 | 12 | 1,8 | 276 | 600 | 850 |
| Ø40 | 12 | 1,8 | 276 | 600 | 850 |
| Ø50 | |||||
| Tip 2 - SN 2 | 12 | 1,8 | 275 | 600 | 850 |
| Tip 1 - SN 4 | 14 | 3 | 257 | 513 | 820 |
| SN 8 | — | — | — | — | — |
| Ø75 | |||||
| Tip 2 - SN 2 | 12 | 1,8 | 240 | 600 | 510 |
| Tip 1 - SN 4 | 14 | 2,2 | 240 | 512 | 510 |
| SN 8 | — | — | — | — | — |
| Ø110 | |||||
| Tip 2 - SN 2 | 14 | 2,2 | 225 | 256 | 450 |
| Tip 1 - SN 4 | 16 | 3,2 | 211 | 225 | 420 |
| SN 8 | — | — | — | — | — |
| Ø125 | |||||
| Tip 2 - SN 2 | 15 | 2,5 | 144 | 240 | 163 |
| Tip 1 - SN 4 | 18 | 3,2 | 120 | 200 | 144 |
| SN 8 | — | — | — | — | — |
| Ø160 | |||||
| Tip 2 - SN 2 | 20 | 3,2 | 112 | 180 | 120 |
| Tip 1 - SN 4 | 23 | 4 | 102 | 156 | 110 |
| SN 8 | — | — | — | — | — |
Tablonun devamını görmek için yatay kaydırın.
What Is a Pipe Belling Machine?
A pipe belling machine is an end-of-line system that heats and shapes the end of a plastic pipe into a socket. This socket allows pipes to be connected securely and helps create standardized, leak-resistant joints.
Which Pipes Can Be Processed with a Belling Machine?
Pipe belling machines are commonly used for PVC, PP, drainage, sewer and pressure pipes. The machine configuration is selected according to pipe diameter, material type, wall thickness and required socket profile.
How Does an Automatic Pipe Socketing Machine Work?
The machine heats the pipe end to the required forming temperature, presses it around a calibrated socket mould and then cools the shaped section. These stages are automatically controlled to maintain consistent socket dimensions.
What Are the Advantages of Infrared Heating in Pipe Belling?
Infrared heating provides uniform heat distribution, faster processing and accurate temperature control. It reduces the risk of uneven softening, surface damage and dimensional variation during socket formation.
What Should Be Considered When Selecting a Pipe Belling Machine?
Pipe material, diameter range, wall thickness, production speed, socket type and heating method should be evaluated. The machine must also be compatible with the extrusion line capacity and required production standards.
